Description
Specifications
Camera
| Features |
· 4 MP 1/2.9" CMOS image sensor, excellent low luminance performance and high definition of images. · Outputs max. 4 MP (2688 × 1520) @25/30 fps. · H.265 codec, high compression rate, ultra-low bit rate. · Built-in IR LED, max. IR distance: 30 m. · ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments. · Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. · Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human). · Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection. · Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic. · 12 VDC/PoE power supply facilitates installation. · IP67, IK10 protection. · SMD 4.0, AI SSA. |
| Lens | 2.8mm Fixed Lens |
| MP | 4MP |
| Image Resolutions | 4M (2688 × 1520), 3.6M (2560 × 1440), 3M (2048×1536), 3M (2304×1296), 1080p (1920 × 1080), 1.3M(1280 × 960), 720p (1280 × 720), D1 (704 × 576/704×480), CIF (352 × 288/352 × 240), VGA (640 × 480) |
| Sensor Size | 1/2.9 CMOS |
| IR Distance | 98 feet |
| IP Rating | IP67 | IK10 |
| Voltage | 12V DC/PoE |
| Temp Range | –40 °F to 140 °F |
| Dimensions | 2.55 by 4.37 inches |
| Weight | 1.17 lb |
| Audio | Built In Mic |
| SD Card Compatible | Micro SD Card ( up to 256Gb can be installed) |
Downloads
Document Downloads
 |
Product Specifications | Detailed Feature List and Product Specifications |
|
Product Manual | Original Product Manuals |
