Description
Specifications
Camera
| Features |
· 5MP 1/2.7" CMOS image sensor, low illuminance, high definition image · Outputs max. 5MP (2592 × 1944)@20 fps and 2688 × 1520 (2688 × 1520)@25/30 fps · H.265 codec, high compression rate, ultra-low bit rate · Built-in efficient warm light and IR LED, and the Max. IR distance is 50 m · ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments · Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes · Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked · Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light during the configured period · Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker, support two-way talk. · 12V DC/PoE power supply, easy for installation · ePoE, IP67 protection · SMD 3.0 |
| Lens | 2.8mm Fixed Lens |
| MP | 5MP |
| Image Resolutions | 5M (2592 × 1944), 4M (2688 × 1520), 4M (2560 × 1440), 3M (2304 × 1296), 1080p (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 |
| Sensor Size | 1/2.7 inch CMOS |
| IR Distance | 164 feet |
| IP Rating | IP67 |
| Voltage | DC 12V (±30%)/PoE (802.3af)/ePoE |
| Temp Range | –40°F to +140°F |
| Dimensions | 4.8 by 4.4 inches |
| Weight | 2.1 lb |
| Audio | Built In Mic |
| SD Card Compatible | Yes |
Downloads
Document Downloads
 |
Product Specifications | Detailed Feature List and Product Specifications |
|
Product Manual | Original Product Manuals |
